Sweepster SB Heavy Duty Pick up broom

• HYDRAULICS: 15 TO 25 GPM, 2000 TO 3500 PSI

The SB Hopper Broom (SSL Collector Sweeper — Hydraulic Drive) by Sweepster handles quick cleanup in construction, municipal and industrial applications. It features a reinforced hopper, a reinforced cutting edge, additional welds between the cutting edge bolts, and five wear bars on the underside of the hopper. This is a bi-directional broom that sweeps forward to pick up dirt in tight areas and the direct-drive bush motor eliminates chains and sprockets.

Standard

• Direct-drive motor powered from loader hydraulics
• 18-25 GPM flow required (2,000-3,500 psi)
• 26" brush diameter
• 5', 6', 7' brush widths available
• Brush head reversible for "dust panning" debris
• Dump bucket by lifting arms
• Quick change core

Heavy duty

• Bi-directional broom sweeps forward to pick up dirt; reverses to sweep in tight areas
• No front caster wheel; works easily next to walls curbs and obstacles
• Replaceable heavy duty bolt-on cutting edge on bucket
• Optional sprinkler kit with or without 25-gallon tank
• Optional gutter brush kit with poly or wire brush
• 5 wear plates on underside of hopper bin
• Reversible, heavy duty cutting edge
• Additional steel reinforcement/welds between bolts and cutting edge and side plates
• Heavy-Duty Bucket Reinforced Sides
• Heavy-Duty Bucket Reinforced Bottom

***CALL FOR SHIPPING PRICES

SPECIFICATIONS

MODEL #	21572M	21584M
WORKING WIDTH	72"	84"
OVER ALL WIDTH	96.5	96.5"
WEIGHT	1190 LB	1190 LB
BRUSH DIAMETER	26"	26"
MIN HYD FLOW	15	15
MAX HYD FLOW	25	25
PSI RANGE	2000 - 3500	2000 - 3500
