Virnig V60 Root Rake Grapple for Skid Steer Loader

The Virnig V60 Root Rake Grapple for Skid Steer Loader is a heavy-duty two-cylinder grapple designed for digging, raking, piling, and loading debris on commercial sites. It’s built for large skid steers and professional crews who demand durable performance and fast material handling.

• All-in-one mounting package: Includes universal skid steer mounting hoses, couplers & fittings and cylinder guards for a ready-to-run attachment.
• Two-position hard stops: Built-in stops in both the open and closed positions protect cylinders during back-dragging or clamping on heavy loads.
• Cast, pin-on teeth: Deep-cutting teeth for aggressive penetration into roots and piles of branches, with long wear life and easy replacement.
• Two-cylinder, single jaw design: Optimized for digging, raking, piling and loading debris with efficient forward and reverse operation to drag material into piles.
• Heavy-duty construction: 1/2" Grade 80 steel jaws and rake tines deliver long-term durability in demanding environments.
• Wide opening for large loads: 53.7" grapple jaw opening enables you to haul substantial amounts of brush per pass.
• Durable hydraulics and bearings: 2-1/2" bore, 8-3/8" stroke cylinders with NitroSteel® rods; greasable pins (1-1/4" and 1-9/16" pins) and Teflon® coated bushings for smooth operation and longevity.
• Machine-specific protection: Includes a hydraulic package designed to protect hose routing and extend system life.
• Size options: Available in 72", 78", and 84" widths to fit a range of loaders; overall dimensions and weight scale with model (see specs).
• Compatibility notes: Some clearance considerations exist with RRG72 on certain Takeuchi track loaders and John Deere G-Series (330G–333G); plan installation accordingly.

The V60 series was designed and constructed for the most demanding applications and the largest skid steers, making it ideal for heavy usage and commercial operations. This attachment enables efficient site cleanup, forestry work, land clearing, and large-scale debris management by combining digging power, precise clamping, and fast material handling in a single tool. With replaceable Series 23 teeth, NitroSteel cylinder rods, and low-maintenance bearings, you can expect extended service life and reduced downtime on challenging jobs. The included universal mounting package and hose protection system help you get productive quickly and stay productive on the job.

Model	72"	78"	84"
Overall Width (in)	74.5	80.5	86.5
Depth (in)	31.6	31.6	31.6
Height: Overall / Bucket (in)	38.3 / 29.7	38.3 / 29.7	38.3 / 29.7
Grapple Jaw Opening (in)	53.7	53.7	53.7
Number of Teeth	7	7	8
Space Between Teeth	9.8	10.8	9.8
Weight (lbs)	1175	1230	1315
