WAIN ROY | Severe-duty rock buckets for Excavators (52,000-65,000 lbs.)

Introducing the WAIN ROY severe-duty rock buckets for excavators 52,000-65,000 lbs, the ultimate solution for handling tough material with ease. Engineered for maximum efficiency, these buckets are designed to facilitate smooth material flow during loading and unloading, ensuring you get the job done faster.

Featuring a low profile bridge design, the bucket provides excellent operator visibility, enhancing safety and precision. The robust construction includes internal struts and a double thickness bridge/moldboard for superior strength and rigidity. Corner gussets reinforce the upper corners while ensuring minimal interference with material flow.

The unique interlocking welded joint at the front corners, combined with a notched cutting edge and replaceable side cutter insert, guarantees a larger and more rigid attaching joint, perfect for abrasive and high-impact applications such as shot rock and caliche.

• Standard Capacity Options:
  • 24" - 0.60 cu. yd - 1658 lbs - 3 Teeth
  • 30" - 0.81 cu. yd - 2080 lbs - 4 Teeth
  • 36" - 1.02 cu. yd - 2179 lbs - 4 Teeth
  • 42" - 1.23 cu. yd - 2308 lbs - 4 Teeth
  • 48" - 1.45 cu. yd - 2519 lbs - 5 Teeth
  • 54" - 1.66 cu. yd - 2699 lbs - 6 Teeth
  • 60" - 1.88 cu. yd - 2929 lbs - 6 Teeth
• High Capacity Options:
  • 24" - 0.81 cu. yd - 1735 lbs - 3 Teeth
  • 30" - 1.08 cu. yd - 2240 lbs - 4 Teeth
  • 36" - 1.36 cu. yd - 2349 lbs - 4 Teeth
  • 42" - 1.64 cu. yd - 2547 lbs - 5 Teeth
  • 48" - 1.93 cu. yd - 2810 lbs - 5 Teeth
  • 54" - 2.23 cu. yd - 3034 lbs - 6 Teeth
  • 60" - 2.52 cu. yd - 3265 lbs - 7 Teeth

Compatible with a variety of makes and models, the WAIN ROY severe-duty rock buckets deliver exceptional performance for excavators ranging from 52,000 to 65,000 lbs. Upgrade your equipment today and experience the difference in efficiency and durability.

Don’t settle for less—choose the best for your excavating needs. Order your WAIN ROY severe-duty rock bucket now and take your productivity to the next level!
