BLUE DIAMOND | Autowing Snow Plow for Skid Steer

Features

• 103" straight blade width for broad snow coverage
• 29" blade height to handle deep accumulation
• Automatic side wings that adjust from scoop mode to wind row as you angle the plow
• Full-trip moldboard to absorb impacts and protect the plow under heavy loads
• Steel cutting edge built for durability and longevity
• Hydraulic angle for precise, quick directional changes
• 6° oscillation to follow ground contours and minimize scalping
• Universal skid steer mount with 1/2" flat-face couplers for broad compatibility
• 2 cylinders delivering reliable blade and wing operation
• Part number 120720 for reference

Benefits

• Increases snow removal productivity by combining the efficiency of a straight blade with the coverage of a winged plow
• Automatic wing adjustment enhances performance under heavy loads, reducing twisting and wear
• Consistent edge quality across uneven surfaces thanks to ground-contour tracking
• Ideal for large lots, commercial properties, municipal loads, and fleet-based snow crews
• Easy integration with many skid steer units thanks to universal mounting and standard couplers
• Durable construction with a steel cutting edge and robust moldboard designed for repeated seasonal use

PART NUMBER	STRAIGHT WIDTH	ANGLED WIDTH	ANGLE	COUPLERS	MOUNT	SIDE MARKERS	CYLINDERS
120720	103”	93.4°	25°	1/2" Flat Face	Universal Skid Steer	Yes	2
