BLUE DIAMOND Hydraulic Breakers for Mini Skid Steer

Blue Diamond’s MINI SKID STEER MOUNT HYDRAULIC BREAKER line delivers compact, reliable demolition power designed specifically for mini skid steers. Built for easy setup, low maintenance, and dependable service, these breakers help you get through demolition, construction, and quarry work with less downtime.

Features

• Mono-block design with no tie rods for simplified servicing and fewer failure points.
• Anti-blank firing system hydraulic brake to protect the tool and machine.
• No re-gassing needed, reducing maintenance steps and downtime.
• Only 2 internal moving parts for increased reliability.
• 2-speed control with variable stroke for adaptable breaking performance
• Quiet operation to minimize site noise impact
• Self-regulating body bushings around the piston to manage wear and vibration
• 3-year warranty for long-term assurance

Available models and key specs

• HB50 — Working pressure 1,750 PSI; Max oil flow 7 GPM; 1,200 BPM; Operating weight 257 lbs; Tool diameter 1.5 in; Energy class 100; Carrier weight 1,500–2,650 lbs; Back pressure 290–360 PSI
• HB95 — Working pressure 1,750 PSI; Max oil flow 11 GPM; 1,200 BPM; Operating weight 355 lbs; Tool diameter 1.8 in; Energy class 200; Carrier weight 2,650–4,000 lbs; Back pressure 290–360 PSI
• HB165 — Working pressure 1,750 PSI; Max oil flow 13 GPM; 1,200 BPM; Operating weight 498 lbs; Tool diameter 2.2 in; Energy class 400; Carrier weight 4,000–6,600 lbs; Back pressure 290–360 PSI
• HB210 — Working pressure 1,750 PSI; Max oil flow 16 GPM; 1,100 BPM; Operating weight 598 lbs; Tool diameter 2.5 in; Energy class 500; Carrier weight 6,100–9,900 lbs; Back pressure 290–360 PSI

Benefits

Designed for the realities of urban demolition, road work, and quarry tasks, these Blue Diamond breakers offer tangible advantages that help you work smarter and longer on tight job sites.

• Efficient power delivery for mini skid steers: the matched pressure and flow profiles speed up cycles while protecting the carrier from overload.
• Low-maintenance operation: a simplified internal design and no re-gassing requirement reduce routine service time and interruptions.
• Reduced downtime: quick setup, reliable performance, and anti-blank firing protection keep projects moving.
• Versatile use across projects: concrete breaking, rock fragmentation, asphalt removal, and trenching prep become more predictable with the right HB model.
• Practical guidance for selection and use: pair HB50/HB95 with smaller machines for nimble handling, or choose HB165/HB210 for heavier mini skid steers needing greater breakout force.

Ideal for contractors, rental fleets, and facilities performing demolition, construction, or quarry work where a compact, durable hydraulic breaker is essential for powering through tough material with control and confidence.

PART NUMBER	MODEL	WORKING PRESSURE	MAX OIL FLOW	FREQUENCY (BPM)	OPERATING WEIGHT	TOOL DIAMETER	ENERGY CLASS	CARRIER WEIGHT	(PSI) BACK PRESSURE
335005	HB50	1,750	7	1,200	257 LBS	1.5	100	1,500-2,650 LBS	290-360
335009	HB95	1,750	11	1,200	355 LBS	1.8	200	2,650-4,000 LBS	290-360
335016	HB165	1,750	13	1,200	498 LBS	2.2	400	4,000-6,600 LBS	290-360
335021	HB210	1,750	16	1,100	598 LBS	2.5	500	6,100-9,900 LBS	290-360
