Stump removal has never been easier with the Baumalight 1P24 PTO stump grinder, expertly designed for compact tractors with a hydrostatic drive and Category 1 3PH. This robust model features a 24-inch rotor with 34 replaceable carbide teeth, achieving an impressive cutting depth of 10 inches above ground and 6 inches below. Suitable for up to 30-inch wide and 12-inch deep stumps, the 1P24 ensures efficient grinding in approximately 15 to 20 minutes, depending on your tractor's horsepower.
The 1P24 PTO stump grinder is designed for small tractors equipped with hydrostatic drive and Category 1 3PH. This tractor mounted stump grinder model allows you to grind small and midsized stumps efficiently with a 24" Rotor, carrying 34 replaceable carbide teeth and has a cutting depth of 10" above ground and 6" below ground with the cutting wheel speed of 540 RPM.
The carbide tipped teeth is 3/4-inch-thick. The maximum cutting depth per pass is 5" and maximum horizontal cut is 22".With no hydraulics required this versatile PTO Stump Grinder is controlled with gravity feed which is ideal for tractors with no hydraulic remotes. In case if there is a sudden advance of the tractor while grinding, the hinge will automatically swing the grinding head out a bit, keeping even pressure on the stump.
The stump grinder unit weight is 350 Lbs having a width and length of 48". A stump of 30" width and 12" depth can be ground in 15 mins with a 40HP tractor, with 30HP it takes around 20 mins. ¾" thick steel rotor acts as a backbone for the stump blaster cutting system.
All Baumalight stump grinders are made in North America and sold through dealers so you always will have local support to service or support your stump grinder.
Does your tractor require our Extension kit
Tractor must have hydro-static drive. On subcompact tractors with short arms, the D005735 Extension kit is required. Before using the 1P24 Stump Grinder, you must first measure your compact tractor to see if you require our D005735 Extension kit.
| Stump Grinder |
|
|
|
|
|
| Recommended HP Size | 20-45 | 20-45 | 25-55 | 45-80 | 60-120 |
| Maximum Engine HP | 45 | 50 | 58 | 85 | 125 |
| Maximum PTO HP | 35 | 40 | 50 | 75 | 115 |
| Transmission | Hydrostatic only | Hydrostatic only | Any | Any | Any |
| Hydraulic GPM | -- | -- | 5–20 | 5–20 | 5–20 |
| Rotor Size | 16" | 24" | 24" | 34" | 34" |
| Number of Teeth | 12 | 34 | 34 | 52 | 52 |
| Tooth Part number | H3000 | S1000 | S1000 | S1000 | S1000 |
| Tooth Construction | High speed round tooth | Carbide steel bolt-in | Carbide steel bolt-in | Carbide steel bolt-in | Carbide steel bolt-in |
| Cutting Wheel Speed | 540 RPM | 540 RPM | 810 RPM | 810 RPM | 1000 RPM |
| Cutting Height - Above Ground | 10" | 10" | 18" | 25" | 25" |
| Cutting Depth - Below Ground | 5" | 6" | 8" | 14" | 14" |
| Maximum Cutting Depth - Per Pass | 2" | 5" | 6" | 9" | 9" |
| Maximum Horizontal Cut | 18" | 22" | 22" | 32" | 32" |
| Swing Arc | 0° | 0° | 65° | 65° | 65° |
| Hub Torque | 664 Ft.-Lbs. | 885 Ft.-Lbs. | 885 Ft.-Lbs. | 1475 Ft.-Lbs. | 1327 Ft.-Lbs. |
| Over Torque Protection | Slip clutch | Slip clutch | Slip clutch | Slip clutch | Slip clutch |
| Hitch | Cat I | Cat I | Cat I or II | Cat II | Cat II |
| Quick hitch compatibility | Yes | Yes | No | No | No |
|
|
0 | 0 | 1 or 2 | 1 or 2 | 1 or 2 |
| Requires 12 Volt DC | No | No | No | No | No |
| Input Speed | 540 | 540 | 540 | 540 | 1000 |
| Unit Weight (Shipping) Lbs. | 360 | 450 | 920 | 1231 | 1280 |
| Width (Shipping) | 36" | 36" | 42" | 48" | 48" |
| Length (Shipping) | 30" | 30" | 49" | 54" | 54" |
